OMCH DR-15-12 modular power supply 230V AC-DC source on DIN 12V/1.25A 15W

1 rating

Code: LA121004D

Brand: OMCH

Encapsulated modular DIN rail power supply suitable not only for industrial applications.

Celý popis

€13,11 €10,83 excl. VAT

+16.39 Bastlíků to Bonus programme

3 pcs

Delivery to:

Free Shipping

From 100 EUR

30 Days to Return

For Registered

Show all related products

Description

Description

Product detailed description

Encapsulated modular DIN rail power supply suitable not only for industrial applications. The power supply has a potentiometric trimmer, which can be used to fine-tune the exact value of the output voltage.

Specifications:

Input voltage: AC 85-264V 47-63Hz
Output voltage: 12V
Output current: max. 1.25A
Output power: max. 15W
Operating temperature range: -20-60°C
Operating RH RH range: 20-90%
Overload protection
Short circuit protection
Overheating protection
Overcurrent protection
Size: 93x56x25mm

Delivery components:

1pc Encapsulated modular DIN rail power supply suitable not only for industrial applications.

Remark:

This product is not a standalone functional unit and may require professional installation.
Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.

Additional parameters

Category:	AC-DC Power Supply
Warranty:	2 years
Weight:	0.095 kg
Výstupní napětí fixní:	12V
Výstupní proud max.:	1-3A
Funkce Konstantní proud:	ne
Input voltage max.:	230V(AC)
Vstupní napětí min.:	50-110V (AC)
Max. Výkon:	12-25W
