VGA Camera OV7670 640x480 + FIFO Buffer AL422B

Product detailed description

Small 0.3M color camera with 640x480 pixels resolution and high quality lens is suitable for connection to Arduino. For communication it uses data transmission over a parallel 8-bit bus, as well as vertical and horizontal synchronization wires and a clock. Supports frame rate up to 30x per second in VGA resolution. Configuration takes place via I2C. The power supply is 3.3V.

Specifications:

• Sensor: OV7670
• FIFO Buffer: AL422B 384KB
• Resolution: 640 x 480 px
• Lens: 1.8/6mm
• Shooting: max. 30 fps
• Visible angle: 25°
• Output format: YUV/YCbCr 4:2:2, RGB 565/555/444, GRB 4:2:2, RAW RGB 8 digit
• Sensitivity: 1.3V (Lux-s)
• Power supply: 2.5-3.0VDC
• Consumption: 60mW/15fpsVGAYUV
• Sleep mode: <20 uA
• Configuration interface: I2C
• Operating temperature: -30 to 70°C
• Signal-to-noise ratio: 46 dB.
• Dynamic range: 52 dB.
• PCB dimensions: 23.5x36.5mm

Included in delivery:

• 1pc VGA Camera OV7670 640x480 + FIFO Buffer AL422B

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
