Strain gauge - bending sensor, 2.2"
Code: LA131143
Free Shipping
From 100 EUR
30 Days to Return
For Registered
30 Days to Return
For Registered Customers
Free Shipping
For orders from 100 EUR
Customer Care
We handle complaints within 5 days
Quick dispatch
Within 24 hours
Related products
Product detailed description
A strain gauge is a passive electrical component used as a sensor to indirectly measure the mechanical stress on the surface of a component by measuring its deformation. The strain gauge is attached to the objects to be measured so that the inside of the metal foil bends with the object.
Specifications:
- Resistance in flat state: 25kΩ
- Power consumption: 0.5W
- Resistance in bent state: 60-110kΩ
- The higher the curvature, the higher the output voltage
- Operating temperature range: -35-80°C
- Sensor dimensions: 73.66x6.35x0.508mm
- Terminal pitch: 2.54mm
- Fatigue life: > 1 million bends
Included in delivery:
- 1pc Tensiometer - bending sensor, 2,2"
Remark:
- This product is not a standalone functional unit and may require professional installation.
- Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
Additional parameters
| Category: | Weight sensors, weight sensors |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.004 kg |
| Output: | Analog |
| Sensor type: | Bend |
