RFID access system with keypad 13,56MHz, IP65

Product detailed description

RFID access system with keypad 13,56MHz, IP65

The access control system with a touch keypad and RFID reader is designed to control access to the building using an RFID card, RFID key fob, or numeric access code, or both. The system has a bell function, which can be used to summon building personnel. The system is also equipped with an alarm when dismounted. Configuration is done using the numeric keypad and therefore no parent system is required.

The device can be switched to the reader mode, when the built-in functions of the access control system are not functional and the device only sends the read codes of the buttons or RFID cards/tags to the master system. For this purpose there is a two-wire interface WG26 on the device.

Specifications:

• Frequency: 13.56MHz
• Power supply: 12V
• Consumption: 100mA
• RFID reading range: 0 - 10cm
• Memory capacity: 1000 records
• Degree of protection: IP65 (outdoor use)
• Dimensions: 120x22x78mm

Included in delivery:

• 1pc RFID access system with keypad 13,56MHz, IP65

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
