Panasonic AMG8833 thermal camera module 64px

Product detailed description

Panasonic AMG8833 thermal camera module 64px

The thermal camera sensor detects non-contact thermal radiation in the infrared spectrum and converts it into electrical signals to generate a thermal image and temperature value on the display. This technology can be used in various industries such as animal protection, vehicle maintenance, medical, circuit protection, military equipment, etc. All kinds of thermal abnormalities that cannot be observed through appearance can be presented in the form of a thermal image. This sensor is composed of an array of 8x8 IR thermal sensors. When connected to the microcontroller, the array returns 64 individual temperature readings using the standard ^I2Cinterface. It's like those fancy thermal cameras, but compact and simple enough for easy integration.

Specifications:

• Power supply: 3-5V
• Current consumption: approx. 4.5mA, in sleep mode approx. 0.2mA
• Temperature range: 0-80°C.
• Temperature measurement accuracy: ±2.5°C
• Number of pixels: 8x8px (64px)
• Communication interface: I ² C
• Dimensions: 25.4x25.4mm

Included in delivery:

• 1pc Panasonic AMG8833 thermal camera module 64px

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
