LilyGO TTGO T-Beam LoRa32 GPS NEO-6M 433MHz WiFi Module

Product detailed description

LoRa IoT platform with integrated GPS, Bluetooth and WIFI module ESP32.

Specifications:

• Lastest ESP32 Version: REV1.2
• Wi-Fi & Bluetooth
• 8MB PSRAM & 4MB Flash
• 3D Antenna
• LORA antenna connector is RG316
• Working voltage: 1.8~3.7v
• Acceptable current: 10~14mA
• Transmit current:
  • 120mA@+20dBm
  • 90mA@+17dBm
  • 29mA@+13dBm
• Operating frequency: 433/470MHz(433HMz version) /868M/915M(868MHz version)
• Transmit power: +20dBm
• Receive sensitivity
  • :-139dBm@LoRa &62.5Khz&SF=12&146bps
  • 136dBm@LoRa &125Khz&SF=12&293bps
  • 118dBm@LoRa &125Khz&SF=6&9380bps
  • 123dBm@FSK&5Khz&1.2Kbps
• Frequency error: +/-15KHz
• FIFO space ： 64Byte
• Data rate：
  • 1.2K~300Kbps@FSK
  • 0.018K~37.5Kbps@LoRa
• Modulation Mode ：FSK,GFSK,MSK,GMSK,LoRa TM，OOK
• Interface form: SPI
• Sleep current：0.2uA@SLEEP
• 1.5uA@IDLE
• Operating temperature: -40℃- +85℃

Delivery components:

• 1pc LilyGO TTGO T-Beam LoRa32 GPS NEO-6M 433MHz WiFi Module
• 1 pc GPS Antenna
• 1pc 433MHz Antenna

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
