LilyGO TTGO T-4 ESP32 2.2 TFT PSARM 8M IP5306 Development Board
Code: LA100106
Free Shipping
From 100 EUR
30 Days to Return
For Registered
30 Days to Return
For Registered Customers
Free Shipping
For orders from 100 EUR
Customer Care
We handle complaints within 5 days
Quick dispatch
Within 24 hours
Product detailed description
Development board based on ESP32 microcontroller. The board includes a 2.2" OLED display, USB-to-UART converter for easy programming and debugging, programmable buttons, SD card slot, I/O expansion connector, and power/charging circuit for battery-powered applications.
Specifications:
|
Hardware |
|
| Chipset | ESPRESSIF-ESP32 240MHz Xtensa® single-/dual-core 32-bit LX6 microprocessor |
| FLASH | QSPI flash/SRAM, 4MB |
| SRAM | PSRAM 8M |
| Button | reset, boot |
| Button | IO37, IO38, IO39 |
| Display | ILI9341 2.2" (240x320) |
| USB to TTL converter | CP2104 |
| Communication interface | SD card, UART, SPI, I2C, PWM, I2S, ADC |
| Oscillator | 40MHz crystal oscillator |
| Supply voltage | 2.3-3.6V |
| Power consumption | about 43mA |
| Power consumption in sleep mode | 1.1mA |
| Audio amplifier | NS4148 |
| Operating temperature range | -40 - +85℃ |
| Dimensions | 66.70x42.59x12.50mm |
|
|
|
| Power | USB 5V/2A |
| Charging current | 2000mA |
| Batteries | 3.7V lithium |
| Power/charge processor | IP5306-I2C |
|
|
|
| Standard | FCC/CE/TELEC/KCC/SRRC/NCC(esp32 chip) |
| Protocols | 802.11 b/g/n/e/i (802.11n，speed up to150Mbps)A-MPDU and A-MSDU polymerization，support 0.4μS Protection interval |
| Frequency range | 2.4GHz~2.5GHz(2400M~2483.5M) |
| Output power | 22dBm |
Bluetooth |
|
| Version | Bluetooth v4.2BR/EDR + BLE |
| Frequency | with -98dBm sensitivity NZIF receiver Class-1,Class-2&Class-3 emitter AFH |
| Audio frequency | CVSD&SBC audio frequency |
|
|
|
| Wi-Fi modes | Station/SoftAP/SoftAP+Station/P2P |
| Safety mechanisms | WPA/WPA2/WPA2-Enterprise/WPS |
| Encryption mechanisms | AES/RSA/ECC/SHA |
| Firmware upgrade | UART download/OTA（Through network/host to download and write firmware) |
| Software development | Support cloud server development /SDK for user firmware development |
| Network protocols | IPv4, IPv6, SSL, TCP/UDP/HTTP/FTP/MQTT |
| User configuration | AT + Instruction set, cloud server, android/iOS app |
| OS | FreeRTOS |
Delivery components:
- 1pc LilyGO TTGO T-4 ESP32 2.2 TFT PSARM 8M IP5306 Development Board
Remark:
- This product is not a standalone functional unit and may require professional installation.
- Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
Additional parameters
| Category: | ESP Development Boards |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.027 kg |
| Type: | ESP |
| Logical levels: | 3.3V |
| I/O pins: | 7 |
| PWM pins: | 7 |
| ADC pins: | 7 |
| Frequency: | 40MHz |
| Flash memory: | 520kB |
| SRAM memory: | 520kB |
| EEPROM memory: | Ne |
| Connector with battery charger: | Yes |
| Microcontroller: | ESP32 |
| Converter: | CP2104 |
| Bluetooth: | Yes |
| WiFi: | Yes |
Be the first who will post an article to this item!
Add a rating
P
Flash paměť
Patrik
Flash paměť
Patrik
Zdravím, v popisku uvádíte, že k této desce mohu přidat až 64 MB flash paměti ("up to 4 x 16 MB"). To by jsem musel odpájet paměťový čip na desce, nebo lze přidat jinak? Předem díky :)
Reply
Reply
MF
Flash paměť
Martin Frajdl
Flash paměť
Martin Frajdl
Dobrý den, jedná se o chybu převzatou ze stránek výrobce. Deska má osazenu FLASH paměť o velikosti 4MB a PSRAM o velikosti 8MB. V popisu opraveno.
