Laser module red 5V 5mW 650nm, cross
During installation, the module halves must not be in conductive contact with other parts of the machine. The use of electrical insulation is essential. Static electricity can destroy the laser immediately.
Specifications:
- Power supply: 3-5 VDC
- Laser color: Red(650nm)
- Beam shape: Cross
- Optical power: 5mW
- Consumption: up to 20mA
- Laser class IIIA
- Diameter: 12mm
- Length: 35mm
- Weight: 15g
Included in delivery:
- 1pc Laser module red 5V 5mW 650nm, cross
Remark:
- This product is not a standalone functional unit and may require professional installation.
- Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
- Avoid any beam striking the human or animal eye during operation. The laser is not safe for human health.
Additional parameters
| Category: | LED and neon modules |
|---|---|
| Warranty: | 2 years |
| Weight: | 0.015 kg |
5,0
1 rating
Add a rating
5
4
3
2
1
5
PP
Petr Prášek
Petr Prášek
Vše v pohodě funkční, použito jako záměrný kříž na 3d tiskárnu. Ze vzdálenosti zhruba 180 má kříž rozměry 150 x 150. Jako zdroj použit 3 x AA Nicd aku, je vhodné předřadit regulovaný zdroj proudu kvůli regulaci intenzity a nezávislosti na vybití akumulátorů.
Dá se nastavit focus.
Tento konkrétní kus při proudu zhruba 16 mA svítí jako czert.
