ISP programmer for ATMEL

Product detailed description

USB ISP programmer for ATMEL AVR with ATmega88 chip

USB programmer for ATMEL AVR microcontrollers. The programmer handles standard programmer functions - reading/writing/verifying FLASH, EEPROM and fuses.

ATTENTION! Works only with PROGISP Ver 1.72 software from Zhifengsoft! The programmer presents itself in the hardware manager as an HID device and for programming software such as. AVRDUDE, or Arduino the IDE is not visible and therefore cannot be used in these programs.

The mentioned PROGISP is available for download in the Related Files tab. No drivers need to be installed for Windows 10, for Windows 7 you can find drivers for download in the same tab as PROGISP.

Specifications:

• Based on ATMega88V chip
• 5 KB/sec Maximum write speed
• 10 pin ISP interface
• Supports Windows, Linux, MAC OS
• Model: MX-USBISP ver 5.0 / ZF-008 HV Programmer ver: 1.6 (ZF-007, ZF-009)

Supported processors:

1. Mega Series

• ATmega8 ATmega48 ATmega88 ATmega168 ATmega328
• ATmega103 ATmega128 ATmega1280 ATmega1281 ATmega16
• ATmega161 ATmega162 ATmega163 ATmega164 ATmega169
• ATmega2560 ATmega2561 ATmega32 ATmega324 ATmega329
• ATmega3290 ATmega64 ATmega640 ATmega644 ATmega649
• ATmega6490 ATmega8515 ATmega8535

Tiny Series

• ATtiny12 ATtiny13 ATtiny15 ATtiny25 ATtiny26
• ATtiny45 ATtiny85 ATtiny2313

Classic Series

• AT90S1200 AT90S2313 AT90S2333 AT90S2343 AT90S4414
• AT90S4433 AT90S4434 AT90S8515
• AT90S8535

CAN Series

• AT90CAN128

PWM Series

• AT90PWM2 AT90PWM3

Included in delivery:

• 1pc ISP programmer for ATMEL
• 1 pc cable

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
