Bluetooth LED controller dimmer 5-24V 72W 2.1/5.5mm

Product detailed description

The single-channel Bluetooth receiver is a great solution for dimming LED lighting that operates with operating voltages from 5 to 24V DC. This receiver is suitable for various types of LED lighting, including LED strips, 5-12V LED bulbs and monochrome LED modules.

One of the notable features of this receiver is its ability to operate on Bluetooth signal. You can place the receiver in places that are not visible, such as behind a plasterboard wall, in a box or in a cupboard. You don't have to have direct visibility, which increases its flexibility in installation.

The receiver has a 2.1/5.5mm DC connector on the input and output, making it easy to connect to power and LED lighting. If the power supply is interrupted and then reconnected, this receiver remembers the last set light intensity. This means that the LED lighting automatically returns to its previous state, which is practical and convenient.

This receiver is the ideal solution for those who want to efficiently control and dim their LED lighting using, for example, their phone while maintaining flexibility in receiver placement.

Driver Features:

• MODE button : - Set the eight effects (hold to turn the controller off, hold to turn the controller on).
• Button B/SPD- : In static color, a short press reduces the intensity in 10 steps. When the effect is short pressed, you decrease the speed of the effect in 10 steps.
• B/SPD+ button : In static colour, a short press increases the intensity in 10 steps. With the short press effect you increase the speed of the effect in 10 steps.

Lighting effects:

The controller has 8 preset lighting effects, which are switched using the MODE + and MODE - buttons. Light effects can be switched to 1.jerky effect, 2.breathing effect, 3. fading brightness and fading end, 4. fading brightness and fading darkness, 5. Strobe, 6. double strobe, 7. triple strobe, 8. flashing

Connection:

Specifications:

• Operating voltage 5-24V DC
• Dimming in the range of 0-100%
• Maximum load 72W
• Range < 30m
• Built-in microphone
• Application: ZENGGE
• Memory of the last set intensity before power interruption
• The driver can control one circuit of LED light sources
• Dimensions: 55x19x11mm

Included in delivery:

• 1pc Bluetooth LED driver dimmer 5-24V 72W 2.1/5.5mm

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
• LED strip and Adapter are not included.
