LaskaKit Esplora, ATmega32U4

Product detailed description

Arduino Esplora is an electronic board equipped with an ATmega32U4 microcontroller. The board is derived from the well-known Leonardo model, but differs with a lot of built-in sensors such as light outputs, joystick, slider, temperature sensor, accelerometer, microphone, light sensor. The device is equipped with two TINKERKIT connectors, through which it is possible to connect a colour LCD display.

You can also easily connect a small TFT display to Esplora and create your own video game.

Esplora and Leonardo differ from all previous Arduino boards in that the ATmega32U4 microcontroller has a built-in USB interface, so there is no need to use additional special circuits to communicate with the computer. The Esplora can appear to the connected computer as either a mouse and keyboard or as a virtual (CDC) serial/COM port.

Specifications:

Microcontroller:

• Chip: ATmega32u4
• Frequency: 16 MHz
• Memory: 32 KB, 4 KB used by bootloader
• SRAM: 2.5 KB
• EEPROM: 1 KB

Inputs and outputs:

• Analog joystick with central button (X and Y axis)
• 4x button
• Linear pull potentiometer
• Amplitude sensing microphone
• Light sensor
• Temperature sensor
• Three-axis accelerometer
• Piezo transducer
• RGB LED diode
• 2x TinkerKit input
• 2x TinkerKit output
• Connector for TFT LCD display (for SPI devices)

Included in delivery:

• 1pc LaskaKit Esplora, ATmega32U4

Remark:

• This product is not a standalone functional unit and may require professional installation.
• Product images are for illustration purposes only and may sometimes differ from the actual appearance of the item. However, this does not change its basic properties.
• The display is not included in the package
